FIRE EXTINGUISHER ABC DRY POWDER MAP-90% STORED PRESSURE 4 KG KANEX

Description Download Technical Datasheet Certifications : IS 15683:2018 Diameter : 140 ± 5 mm Height : 490 mm Approx. Thickness of sheet : Made up from 1.6mm thick sheet Full weight of extinguisher : 6.7kg (Approx.) Extinguishing medium : Mono Ammonium Phosphate (MAP-90%) dry powder (IS 4308:2019) Body : Mild Steel Sheet having Max. of 0.25% C, 0.05% P and 0.05% S (IS 513) Neck Ring : MS Pipe – M30×1.5 Female threaded Valve : Brass – M30×1.5 Male threaded Siphon tube : PVC / Plastic Pressure gauge / indicator : As per IS 15683:2018 Discharge hose with nozzle : Rubber braided EPDM hose with PVC nozzle (Burst pressure ≥ 55 bar) Wall mounting bracket with screw : MS Powder coated Fire rating : 4A : 144B Performance requirements : • Min. Effective discharge time : 15 Sec. (Actual: 18 Sec. Approx.) • Min. Bulk range of discharge : 2 Mtr. (Actual: 3 Mtr. Approx.) • Min. Percentage of discharge : 85% (Actual: 94% Approx.) Temperature Range : -30° to 60°C Service pressure : 15 bar Max. service pressure : 18 bar Hydro Pressure Test (Pt) : 35 bar (3.5 MPa) Hold for 2.5 min. Min. Burst pressure (Pb) for body : 55 bar (5.5 MPa) Hold for 1 min. Leakage test : Inverted glass jar / Soap solution Partial discharge : The second pressure or weight shall not be less than 75% of the first after interruption of the discharge
