3 Way Active Crossover Filter Board

3-Way Active Crossover Filter Board (Linkwitz-Riley, Assembled)This assembled board is designed for audio signal separation into low, mid, and high frequency bands using Linkwitz-Riley filter topology.Working Voltage:Dual supply: ±12 V DC (regulated supply required)Signal Processing:Three separate outputs: Low, Mid, and High frequency bandsSignal gain: up to 20 dB (depends on circuit configuration)RF input filter for reduction of unwanted noiseOp-Amp Configuration:Uses NE5532 and TL084 op-amp ICsProtection Features:Reverse polarity protection using diodesConnectors:2.54 mm JST / Relimate connectors for input, output, and power connectionsBoard Specifications:PCB dimensions: 103 mm × 53 mmCompact layout for enclosure integrationConstruction:Fully assembled boardUses through-hole componentsConfiguration:Requires regulated ±12 V DC power supplyDesigned for integration with multi-channel amplifier systemsIntended Use:Active speaker systems with separate low, mid, and high frequency driversMulti-way audio amplifier setupsDIY audio crossover and signal processing applications
